MNIST Digit Classifier using Vision Transformer (ViT) 🖼️➡️🔢🧠

A project by Team Backprop Bunch 🎉 (Yurii, Amy, Guillaume, Aygun) for Week 3 of the MLX Institute Intensive Program.

Project Overview 📋

This project implements a Vision Transformer (ViT) from scratch to classify MNIST digits. We are tackling this progressively in three phases:

1. ✅ Phase 1: Recognize a single MNIST digit (28x28 image).
2. ✅ Phase 2: Recognize four MNIST digits arranged in a 2x2 grid (56x56 image).
3. ➡️ Phase 3: Recognize a dynamic number of digits (0-N) placed randomly within a larger image (e.g., 64x64), including identifying empty spaces.

The core idea is to adapt the Transformer architecture (using self-attention) to process images by splitting them into patches, removing the need for traditional convolutions.

Key Features & Modules 🛠️

• Configuration: ⚙️ Centralized parameters via config.yaml (image size, patch size, ViT architecture dimensions, training settings per phase).
• Data Handling (src/mnist_transformer/dataset.py): 🔄 Loads standard MNIST (torchvision), generates synthetic 2x2 grid data for Phase 2. Includes data transformations. (Phase 3 generation pending).
• ViT Modules (src/mnist_transformer/modules.py): 🧩 Defines core ViT components from scratch: PatchEmbedding, Attention (Multi-Head Self-Attention using AttentionHead), MLPBlock, TransformerEncoderBlock.
• Model Architecture (src/mnist_transformer/model.py): 🏗️ Defines the main VisionTransformer class, assembling the modules and adapting its input/output structure for Phase 1 and Phase 2.
• Training (src/mnist_transformer/trainer.py): 🏋️‍♀️ Implements the training and evaluation loops using Cross-Entropy Loss (adapted for multi-output in Phase 2), AdamW optimizer, and basic LR scheduling.
• Utilities (utils/): 🔧 Shared functions for logging (with color!), device (CPU/MPS/CUDA) setup, config loading, artifact saving.
• Experiment Tracking (wandb): 📊 Integrated for logging hyperparameters, metrics (loss, accuracy - batch and epoch), model gradients, and saving final artifacts.
• Main Script (scripts/train_mnist_vit.py): 🚀 Orchestrates loading, setup, training (selecting the phase via --phase), evaluation, and saving process.

Current Status & Results 📈📉

• ✅ Phase 1 Complete: Successfully trained a small ViT (Depth=4, Embed=64, Heads=4) on single MNIST digits, achieving ~98.3% validation accuracy after 15 epochs.
• ✅ Phase 2 Complete: Successfully adapted the model and training logic for the 2x2 grid task. Trained for 20 epochs, achieving ~95.7% validation accuracy (accuracy calculated per digit).
• ✅ Core Modules Built: Implemented ViT components including Multi-Head Self-Attention from scratch.
• ✅ Pipeline Functional: End-to-end training and evaluation pipeline is working, including W&B integration and artifact saving.

Directory Structure 📁

A detailed breakdown is available in docs/STRUCTURE.MD.

Setup 💻

1. Clone the Repository: 📥

   # TODO: Update with correct Week 3 Repo URL
   git clone https://github.com/YOUR_ORG/mlx-w3-mnist-transformer.git
   cd mlx-w3-mnist-transformer

2. Create & Activate Virtual Environment: 🐍

   python3 -m venv .venv
   source .venv/bin/activate  # On Windows use `\.venv\Scripts\activate`

3. Install Dependencies: 📦

   pip install -r requirements.txt
   # You might need: pip install torchinfo matplotlib seaborn pandas # If not already included

4. Weights & Biases Login: 🔑

   wandb login

5. MNIST Data: 🗃️ The MNIST dataset will be downloaded automatically by torchvision into the data/ directory the first time you run the training script.

Usage 🚦

1. Configuration: ⚙️ Review config.yaml. Phase 1 and 2 parameters are set. Phase 3 parameters are placeholders.
2. Run Training: 🏃‍♂️ Execute the main training script from the project root directory:

   # Train Phase 1 (Example: 15 epochs, default LR from config)
   python scripts/train_mnist_vit.py --phase 1 --epochs 15

   # Train Phase 2 (Example: 20 epochs, default LR from config)
   python scripts/train_mnist_vit.py --phase 2 --epochs 20

   # Override LR for a phase
   # python scripts/train_mnist_vit.py --phase 1 --epochs 10 --lr 5e-4

   • Training progress (tqdm bars) shown in console.
   • Metrics logged to Weights & Biases (link provided).
   • Model artifacts saved locally under models/mnist_vit/<W&B_RUN_NAME>/.

Use python scripts/train_mnist_vit.py --help for command-line options.

Phased Plan & Next Steps 🔮

• ✅ Phase 1: Single Digit Recognition: DONE.
• ✅ Phase 2: 2x2 Grid Recognition: DONE.
• ➡️ Phase 3: Dynamic Layout Recognition: Implement dynamic data generation (dataset.py), adapt model output (model.py), adapt loss/accuracy calculation (trainer.py), update main script & config. Use Grid Classification approach with "Empty" class (see notebooks/03_phase3_design_ideas.ipynb).
• ✨ Apply Training Tricks: Consider adding LR Warmup, more sophisticated LR scheduling, stronger augmentation, or regularization like Stochastic Depth if needed for Phase 3 or further refinement.
• 📊 Evaluation Script: Fully implement scripts/evaluate.py for standalone evaluation of saved models.
